Battery Type |
Capacity AH (10 HR) |
Dimension - Millimeters (± 2 mm) | Assembly figure (as per cover polarity) |
Weight W/O acid Kg |
Terminal Type |
Acid Volume (L) |
Regular Charge Current (AMP) |
C.C.A. @ 0°F (-18°c) |
||
L | W | H | ||||||||
6N4-MF | 4 | 70 | 70 | 95 | 0.581 | - | 0.135 | 0.4 | - | |
YTR4A-BS | 2.3 | 114 | 49 | 86 | 0.89 | I | 0.12 | 0.3 | 45 | |
GTX2.5-BS | 2.5 | 80 | 70 | 105 | 0.86 | - | 0.174 | 0.3 | ||
YTX3L-BS | 3 | 99 | 57 | 111 | 1.05 | B | 0.15 | 0.3 | ||
GT3L-BS | 3 | 99 | 57 | 111 | 1.05 | B | 0.15 | 0.3 | ||
GT4L-BS | 3 | 114 | 71 | 86 | 1.13 | A/D | 0.192 | 0.4 | 50 | |
YT4L-BS | 3 | 114 | 71 | 86 | 1.13 | A/D | 0.192 | 0.4 | 50 | |
CT4L-BS | 3 | 114 | 71 | 86 | 1.13 | A/D | 0.192 | 0.4 | 50 | |
YTH4L-BS | 3 | 114 | 71 | 86 | 1.13 | A | 0.192 | 0.4 | 50 | |
GTX4L-BS | 3 | 114 | 71 | 86 | 1.13 | A/D | 0.192 | 0.4 | 50 | |
YTX4L-BS | 3 | 114 | 71 | 86 | 1.13 | A/D | 0.192 | 0.4 | 50 | |
GT4AL-BS | 4 | 120 | 71 | 92 | 1.15 | A | 0.198 | 0.4 | - | |
GTX4AL-BS | 4 | 120 | 71 | 92 | 1.15 | A | 0.198 | 0.4 | - | |
YTX5L-BS | 4 | 114 | 71 | 106 | 1.38 | A/D | 0.24 | 0.5 | 70 | |
YT5L-BS | 4 | 114 | 71 | 106 | 1.38 | A/D | 0.24 | 0.5 | ||
GTX5L-BS | 4 | 114 | 71 | 106 | 1.38 | A/D | 0.24 | 0.5 | ||
GT5L-BS | 4 | 114 | 71 | 106 | 1.38 | A/D | 0.24 | 0.5 | ||
CT5L-BS | 4 | 114 | 71 | 106 | 1.38 | A/D | 0.24 | 0.5 | ||
GT5AL-BS | 5 | 120 | 60 | 130 | 1.48 | B | 0.276 | 0.5 | ||
GTX6.5-BS | 6 | 137 | 66 | 98 | 1.55 | B | 0.27 | 0.5 | ||
YTX7A-BS | 6 | 150 | 87 | 94 | 1.86 | A | 0.366 | 0.7 | 90 | |
YT7A-BS | 6 | 150 | 87 | 94 | 1.86 | A | 0.366 | 0.7 | ||
GTX7A-BS | 6 | 150 | 87 | 94 | 1.86 | A | 0.366 | 0.7 | ||
GTX7DL-BS | 7 | 148 | 60 | 130 | 1.79 | B | 0.36 | 0.7 | ||
GTX9A-BS | 8 | 150 | 87 | 105 | 2.23 | A | 0.432 | 0.9 | ||
GTX9-BS | 8 | 150 | 87 | 105 | 2.23 | A | 0.432 | 0.9 | ||
CTX9-BS | 8 | 150 | 87 | 105 | 2.23 | A | 0.432 | 0.9 | ||
YTX9-BS | 8 | 150 | 87 | 105 | 2.23 | A | 0.432 | 0.9 | ||
GTX9A-BS | 9 | 137 | 76 | 140 | 2.397 | B | 0.456 | 0.9 | ||
YTX9L-BS | 9 | 137 | 76 | 140 | 2.397 | B | 0.456 | 0.9 | ||
YT12A-BS | 8.7 | 150 | 87 | 105 | 2.534 | A | 0.45 | 0.9 | 175 |
