Battery Type |
Capacity AH (10 HR) |
Dimension - Millimeters (± 2 mm) | Assembly figure (as per cover polarity) |
Weight W/O acid Kg |
Terminal Type |
Acid Volume (L) |
Regular Charge Current (AMP) |
||
L | W | H | |||||||
YB2.5L-C | 2.5 | 80 | 70 | 105 | 0.79 | - | 0.29 | 0.3 | |
CB2.5L-C | 2.5 | 80 | 70 | 105 | 0.79 | - | 0.29 | 0.3 | |
YB2.5L-C-1 | 2.5 | 80 | 70 | 105 | 0.79 | - | 0.29 | 0.3 | |
YB2.5L-C-2 | 2.5 | 80 | 70 | 105 | 0.79 | - | 0.29 | 0.3 | |
YB3L-A | 3 | 98 | 56 | 110 | 0.97 | B | 027 | 0.3 | |
CB3L-A | 3 | 98 | 56 | 110 | 0.97 | B | 027 | 0.3 | |
YB3L-B | 3 | 98 | 56 | 110 | 0.97 | B | 027 | 0.3 | |
CB3L-B | 3 | 98 | 56 | 110 | 0.97 | B | 027 | 0.3 | |
GM3-3 B | 3 | 99 | 57 | 111 | 0.97 | B | 027 | 0.3 | |
YB4L-A | 4 | 120 | 70 | 92 | 1.18 | A | 0.33 | 0.4 | |
CB4L-A | 4 | 120 | 70 | 92 | 1.18 | A | 0.33 | 0.4 | |
YB4L-B | 4 | 120 | 70 | 92 | 1.18 | A | 0.33 | 0.4 | |
CB4L-B | 4 | 120 | 70 | 92 | 1.18 | A | 0.32 | 0.4 | |
CB5L-A | 5 | 120 | 60 | 130 | 1.4 | B | 0.44 | 0.5 | |
YB5L-B | 5 | 120 | 60 | 130 | 1.4 | B | 0.44 | 0.5 | |
CB5L-B | 5 | 120 | 60 | 130 | 1.4 | B | 0.44 | 0.5 | |
GM5Z-3B | 5 | 120 | 61 | 131 | 1.4 | B | 0.44 | 0.5 | |
YB6L-B | 6 | 135 | 70 | 95 | 1.51 | B | 0.44 | 0.6 | |
YB6.5L-B | 6 | 138 | 65 | 102 | 1.554 | B | 0.44 | 0.6 | |
YB6.5AL-B | 6 | 138 | 65 | 102 | 1.554 | B | 0.44 | 0.6 | |
YB7-A | 7 | 135 | 75 | 133 | 1.77 | B | 0.7 | 0.7 | |
CB7-A | 7 | 135 | 75 | 133 | 1.77 | B | 0.7 | 0.7 | |
CB7-A2 | 7 | 135 | 75 | 133 | 1.77 | A | 0.7 | 0.7 | |
YB7A-A | 7 | 135 | 75 | 148 | 1.79 | B | 0.7 | 0.7 | |
CB7A-A | 7 | 135 | 75 | 148 | 1.79 | B | 0.7 | 0.7 | |
CB7A-B | 7 | 135 | 75 | 148 | 1.79 | B | 0.7 | 0.7 | |
YB7B-B | 7 | 150 | 60 | 130 | 1.75 | B | 0.5 | 0.7 | |
CB7B-B | 7 | 150 | 60 | 130 | 1.75 | B | 0.5 | 0.7 | |
YB7C-A | 8 | 130 | 90 | 114 | 1.80 | E | 0.7 | 0.8 | |
YB7L-A | 7 | 135 | 75 | 133 | 1.77 | B | 0.7 | 0.7 | |
YB7L-B | 7 | 135 | 75 | 133 | 1.77 | B | 0.7 | 0.7 | |
CB7L-B | 7 | 135 | 75 | 133 | 1.77 | B | 0.7 | 0.7 | |
YB9A-A | 9 | 135 | 75 | 155 | 2.21 | B | 0.7 | 0.9 | |
CB9A-A | 9 | 135 | 75 | 155 | 2.21 | B | 0.7 | 0.9 | |
CB9-A | 9 | 135 | 75 | 139 | 2.18 | B | 0.7 | 0.9 | |
YB9-B | 9 | 135 | 75 | 139 | 2.18 | B | 0.7 | 0.9 | |
YB9L-B | 9 | 135 | 75 | 139 | 2.18 | B | 0.7 | 0.9 | |
CB9L-B | 9 | 135 | 75 | 139 | 2.18 | B | 0.7 | 0.9 | |
YB9L-A2 | 9 | 135 | 75 | 139 | 2.18 | C | 0.7 | 0.9 | |
CB9L-A2 | 9 | 135 | 75 | 139 | 2.18 | C | 0.7 | 0.9 | |
YB10A-A2 | 11 | 135 | 90 | 155 | 2.98 | D | 0.99 | 1.1 | |
CB10A-A2 | 11 | 135 | 90 | 155 | 2.98 | D | 0.99 | 1.1 | |
YB10L-A2 | 11 | 135 | 90 | 145 | 2.96 | D | 0.99 | 1.1 | |
CB10L-A2 | 11 | 135 | 90 | 145 | 2.96 | D | 0.99 | 1.1 | |
YB10L-B | 11 | 135 | 90 | 145 | 2.96 | B | 0.99 | 1.1 | |
CB10L-B | 11 | 135 | 90 | 145 | 2.96 | B | 0.99 | 1.1 | |
YB10L-B2 | 11 | 135 | 90 | 145 | 2.96 | D | 0.99 | 1.1 | |
YB12A-A | 12 | 134 | 80 | 160 | 3.1 | B | 0.99 | 1.2 | |
CB12A-A | 12 | 134 | 80 | 160 | 3.1 | B | 0.99 | 1.2 | |
YB12AL-A | 12 | 134 | 80 | 160 | 3.1 | B | 0.99 | 1.2 | |
YB12AL-A2 | 12 | 134 | 80 | 160 | 3.1 | B | 0.99 | 1.2 | |
YB12A-B | 12 | 134 | 80 | 160 | 3.1 | B | 0.99 | 1.2 | |
CB12A-B | 12 | 134 | 80 | 160 | 3.1 | B | 0.99 | 1.2 | |
YB16-B-CX | 19 | 175 | 100 | 155 | 4.516 | B | 1.47 | 1.9 | |
YB16HL-A-CX | 19 | 175 | 100 | 155 | 4.516 | B | 1.47 | 1.9 | |
Y50-N18L-A-CX | 20 | 205 | 90 | 162 | 5.19 | C | 1.47 | 2.0 | |
YB12B-B2 | 12 | 160 | 90 | 130 | 2.95 | D | 0.99 | 1.2 | |
CB12B-B2 | 12 | 160 | 90 | 130 | 2.95 | D | 0.99 | 1.2 | |
YB12C-A | 12 | 134 | 80 | 175 | 3.12 | A | 0.99 | 1.2 | |
CB12C-A | 12 | 134 | 80 | 175 | 3.12 | A | 0.99 | 1.2 | |
YB14-A2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
CB14-A2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
YB14A-A1 | 14 | 134 | 89 | 176 | 3.58 | B | 0.99 | 1.4 | |
YB14A-A2 | 14 | 134 | 89 | 176 | 3.58 | D | 0.99 | 1.4 | |
YB14L-A1 | 14 | 134 | 89 | 166 | 3.565 | E | 0.99 | 1.4 | |
YB14L-A2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
CB14L-A2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
YB14L-B2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
CB14L-B2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
YB14-B2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
CB14-B2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
SYB14L-A2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
YB16AL-A2 | 16 | 207 | 71.5 | 164 | 3.75 | F | 147 | 1.6 | |
CB16AL-A2 | 16 | 207 | 71.5 | 164 | 3.75 | F | 147 | 1.6 | |
HYB16A-AB | 16 | 151 | 91 | 180 | 3.42 | C | 147 | 1.6 | |
YB16-B | 19 | 175 | 100 | 155 | 4.516 | B | 147 | 1.9 | |
CB16-B | 19 | 175 | 100 | 155 | 4.516 | B | 147 | 1.9 | |
CB16L-A | 19 | 175 | 100 | 155 | 4.516 | B | 147 | 1.9 | |
YB16L-B | 19 | 175 | 100 | 155 | 4.516 | B | 147 | 1.9 | |
CB16L-B | 19 | 175 | 100 | 155 | 4.516 | B | 147 | 1.9 | |
YB16B-A | 16 | 160 | 90 | 161 | 3.71 | A | 147 | 1.6 | |
CB16B-A | 16 | 160 | 90 | 161 | 3.71 | A | 147 | 1.6 | |
YB16B-A1 | 16 | 160 | 90 | 161 | 3.71 | A | 147 | 1.6 | |
CB16B-A1 | 16 | 160 | 90 | 161 | 3.71 | A | 147 | 1.6 | |
YB16C-B | 19 | 175 | 100 | 175 | 4.72 | A | 147 | 1.9 | |
YB16CL-B | 19 | 175 | 100 | 175 | 4.72 | A | 147 | 1.9 | |
CB16CL-B | 19 | 175 | 100 | 175 | 4.72 | A | 147 | 1.9 | |
HCB16A-A(B) | 16 | 151 | 91 | 180 | 3.42 | C | 147 | 1.9 | |
YB18-A | 18 | 180 | 90 | 162 | 4.51 | C | 147 | 1.6 | |
YB18L-A | 18 | 180 | 90 | 162 | 4.51 | C | 147 | 1.8 | |
C50-N18A-A | 20 | 205 | 90 | 176 | 5.20 | C | 147 | 1.8 | |
Y50-N18A-A | 20 | 205 | 90 | 176 | 5.20 | C | 147 | 2.0 | |
C50-N18L-A | 20 | 205 | 90 | 162 | 5.19 | C | 147 | 2.0 | |
Y50-N18L-A | 20 | 205 | 90 | 162 | 5.19 | C | 147 | 2.0 | |
C50-N18L-A2 | 20 | 205 | 90 | 162 | 5.19 | A | 147 | 2.0 | |
C50-N18L-A3 | 20 | 205 | 90 | 162 | 5.19 | A | 147 | 2.0 | |
Y50-N18L-A3 | 20 | 205 | 90 | 162 | 5.19 | C | 147 | 2.0 | |
C50-N18L-AT | 20 | 205 | 90 | 162 | 5.19 | C | 147 | 2.0 | |
SC50-N18L-A | 20 | 205 | 90 | 162 | 5.19 | C | 147 | 2.0 | |
SY50-N18L-AT | 20 | 205 | 90 | 162 | 5.19 | C | 147 | 2.0 | |
Y60-N24-A | 28 | 184 | 124 | 175 | 6.09 | G | 2.1 | 2.0 | |
Y60-N24L-A | 28 | 184 | 124 | 175 | 6.09 | G | 1.8 | 2.8 | |
Y60-N30L-A | 30 | 184 | 128 | 169 | 6.77 | G | 1.8 | 2.8 | |
C60-N24L-A | 28 | 184 | 124 | 175 | 6.99 | G | 1.8 | 3.0 | |
C60-N24AL-B | 28 | 184 | 124 | 175 | 6.99 | G | 1.8 | 2.8 | |
C60-N28L-A | 28 | 184 | 128 | 169 | 6.277 | G | 1.8 | 2.8 | |
C60-N30L-A | 30 | 184 | 128 | 169 | 6.77 | G | 1.8 | 2.8 | |
YB30L-B | 30 | 168 | 132 | 176 | 7.475 | A | 1.8 | 3.0 | |
YB30CL-B | 30 | 168 | 132 | 192.2 | 7.50 | A | 1.8 | 3.0 | |
CHD4-12(H-12) | 28 | 206 | 133 | 165 | 7.118 | H | 1.8 | 3.0 | |
SCB12A-A | 12 | 134 | 80 | 160 | 3.1 | B | 0.99 | 2.8 | |
SCB14L-A2 | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.2 | |
51814 | 19 | 186 | 82 | 171 | 4.51 | G | 0.99 | 1.4 | |
51913 | 19 | 186 | 82 | 171 | 4.51 | G | 0.99 | 1.9 | |
53030 | 30 | 186 | 130 | 171 | 6.77 | G | 182 | 3.0 |
