Battery Type |
Capacity AH (10 HR) |
Dimension - Millimeters (± 2 mm) | Assembly figure (as per cover polarity) |
Weight W/O acid Kg |
Terminal Type |
Acid Volume (L) |
Regular Charge Current (AMP) |
||
L | W | H | |||||||
6N2-2A | 2 | 70 | 47 | 96 | 0.40 | - | 0.19 | 0.2 | |
6N2-2A-1 | 2 | 70 | 47 | 96 | 0.40 | - | 0.19 | 0.2 | |
6N2-2A-2 | 2 | 70 | 47 | 96 | 0.40 | - | 0.19 | 0.2 | |
6N2-2A-3 | 2 | 70 | 47 | 96 | 0.40 | - | 0.19 | 0.2 | |
6N2-2A-4 | 2 | 70 | 47 | 96 | 0.40 | - | 0.19 | 0.2 | |
6N2-2A-5 | 2 | 70 | 47 | 96 | 0.40 | - | 0.19 | 0.2 | |
6N2-2A-6 | 2 | 70 | 47 | 96 | 0.40 | - | 0.19 | 0.2 | |
6N2-2A-7 | 2 | 70 | 47 | 96 | 0.40 | - | 0.19 | 0.2 | |
6N2-2A-8 | 2 | 70 | 47 | 96 | 0.40 | - | 0.19 | 0.2 | |
6N4-2A | 4 | 71 | 71 | 96 | 0.56 | - | 0.2 | 0.4 | |
6N4-2A-2 | 4 | 71 | 71 | 96 | 0.56 | - | 0.2 | 0.4 | |
6N4-2A-3 | 4 | 71 | 71 | 96 | 0.56 | - | 0.2 | 0.4 | |
6N4-2A-4 | 4 | 71 | 71 | 96 | 0.56 | - | 0.2 | 0.4 | |
6N4-2A-5 | 4 | 71 | 71 | 96 | 0.56 | - | 0.2 | 0.4 | |
6N4-2A-6 | 4 | 71 | 71 | 96 | 0.56 | - | 0.2 | 0.4 | |
6N4-2A-7 | 4 | 71 | 71 | 96 | 0.56 | - | 0.2 | 0.4 | |
6N4-2A-8 | 4 | 71 | 71 | 96 | 0.56 | - | 0.2 | 0.4 | |
6N4-2B | 4 | 102 | 48 | 96 | 0.67 | - | 0.2 | 0.4 | |
6N4A-4D | 4 | 58 | 62 | 131 | 0.61 | - | 0.2 | 0.4 | |
6N4A-4D-1 | 4 | 58 | 62 | 131 | 0.61 | - | 0.2 | 0.4 | |
6N4B-2A | 4 | 102 | 48 | 96 | 0.67 | - | 0.22 | 0.4 | |
6N4B-2A-1 | 4 | 102 | 48 | 96 | 0.67 | - | 0.22 | 0.4 | |
6N4B-2A-2 | 4 | 102 | 48 | 96 | 0.67 | - | 0.22 | 0.4 | |
6N4B-2A-3 | 4 | 102 | 48 | 96 | 0.67 | - | 0.22 | 0.4 | |
6N4B-2A-4 | 4 | 102 | 48 | 96 | 0.67 | - | 0.22 | 0.4 | |
6N4B-2A-5 | 4 | 102 | 48 | 96 | 0.67 | - | 0.22 | 0.4 | |
6N6-1B | 6 | 99 | 57 | 109 | 0.76 | - | 0.27 | 0.6 | |
6N6-1B -1 | 6 | 99 | 57 | 109 | 0.76 | - | 0.27 | 0.6 | |
6N6-3B | 6 | 99 | 57 | 109 | 0.76 | B | 0.27 | 0.6 | |
6N6-3B-1 | 6 | 99 | 57 | 109 | 0.76 | B | 0.27 | 0.6 | |
6N6-1D | 6 | 99 | 57 | 111 | 0.76 | - | 0.27 | 0.6 | |
6N6-1D-1 | 6 | 99 | 57 | 111 | 0.76 | - | 0.27 | 0.6 | |
6N6-1D-2 | 6 | 99 | 57 | 111 | 0.76 | - | 0.27 | 0.6 | |
6N6-1C | 6 | 99 | 57 | 111 | 0.76 | - | 0.27 | 0.6 | |
B39-6(6N7-1) | 7 | 126 | 48 | 126 | 1.11 | B | 0.33 | 0.7 | |
6N11-2D | 11 | 150 | 70 | 100 | 1.352 | B | 0.4 | 1.1 | |
B49-6 | 10 | 90 | 82 | 159 | 1.378 | B | 0.5 | 1.0 | |
6N11-4D | 11 | 150 | 70 | 100 | 1.352 | B | 0.44 | 1.1 | |
6N11A-1B | 11 | 122 | 58 | 129 | 1.261 | B | 0.33 | 1.1 | |
6N11A-3 | 11 | 122 | 58 | 132 | 1.27 | B | 0.33 | 1.1 | |
6N11A-4 | 11 | 122 | 58 | 132 | 1.27 | B | 0.33 | 1.1 | |
6N12A-2C(B54-B | 12 | 156 | 57 | 116 | 1.515 | B | 0.53 | 1.2 | |
6N12A-2D(B54-6A) | 12 | 156 | 57 | 116 | 1.515 | B | 0.53 | 1.2 | |
B38-6A | 13 | 118 | 82 | 159 | 1.77 | B | 0.7 | 1.3 | |
6N12 | 12 | 105 | 77 | 140 | 1.46 | B | 0.53 | 1.2 | |
6N14 | 14 | 105 | 77 | 140 | 1.46 | B | 0.53 | 1.4 | |
6V18AH | 18 | 122 | 87 | 140 | 1.931 | B | 0.58 | 1.8 | |
12N2.5-3C | 2.5 | 81 | 71 | 106 | 0.79 | - | 0.29 | 0.3 | |
12N3-3A | 3 | 99 | 57 | 111 | 0.97 | B | 0.27 | 0.3 | |
12N3-3B | 3 | 99 | 57 | 111 | 0.97 | B | 0.27 | 0.3 | |
12N4-3B | 4 | 121 | 71 | 93 | 1.18 | D | 0.33 | 0.4 | |
12N5-3B | 5 | 120 | 60 | 130 | 1.4 | B | 0.44 | 0.5 | |
12N5-4B | 5 | 120 | 60 | 130 | 1.4 | B | 0.44 | 0.5 | |
12M5-D | 5 | 135 | 70 | 95 | 1.51 | B | 0.44 | 0.5 | |
12N5.5-3B | 5.5 | 138 | 61 | 131 | 1.41 | B | 0.5 | 0.6 | |
12N5.5-4B | 5.5 | 138 | 61 | 131 | 1.41 | B | 0.5 | 0.6 | |
12N5.5A-3B | 5.5 | 103 | 91 | 114 | 1.384 | B | 0.5 | 0.6 | |
12N5.5A-4B | 5.5 | 103 | 91 | 114 | 1.384 | B | 0.5 | 0.6 | |
12N6-3B | 6 | 135 | 70 | 95 | 1.384 | B | 0.44 | 0.6 | |
12N6.5-3B | 6 | 138 | 65 | 102 | 1.51 | B | 0.44 | 0.6 | |
12N7 | 7 | 135 | 76 | 120 | 1.554 | B | 0.5 | 0.7 | |
12N7-3B | 7 | 135 | 75 | 133 | 1.91 | B | 0.7 | 0.7 | |
12N7-4A | 7 | 135 | 75 | 133 | 1.77 | B | 0.7 | 0.7 | |
12N7-4B | 7 | 135 | 75 | 133 | 1.77 | B | 0.7 | 0.7 | |
12N7A-3A | 7 | 148 | 61 | 131 | 1.77 | B | 0.5 | 0.7 | |
12N7-4LB | 7 | 148 | 61 | 131 | 175 | B | 0.5 | 0.7 | |
12N7B-3A | 7 | 148 | 61 | 131 | 175 | B | 0.5 | 0.7 | |
12N7B-4A | 7 | 148 | 61 | 131 | 175 | B | 0.5 | 0.7 | |
12N7B-4B | 7 | 150 | 87 | 95 | 175 | A | 0.5 | 0.7 | |
12M7B-4B | 7 | 148 | 61 | 131 | 1.86 | B | 0.5 | 0.7 | |
12N7C-3B | 6 | 138 | 65 | 102 | 1.554 | B | 0.44 | 0.6 | |
12N7C-3D | 8 | 130 | 90 | 114 | 1.8 | E | 0.7 | 0.8 | |
12N7CZ-3D | 8 | 130 | 90 | 114 | 1.8 | E | 0.7 | 0.8 | |
12N7D-3B | 7 | 135 | 75 | 150 | 1.78 | B | 0.7 | 0.7 | |
12M8-3B | 8 | 135 | 75 | 133 | 1.77 | B | 0.7 | 0.8 | |
12N9-3A | 9 | 135 | 75 | 139 | 2.18 | B | 0.7 | 0.9 | |
12N9-3A-1 | 9 | 135 | 75 | 139 | 2.18 | B | 0.7 | 0.9 | |
12N9-3B | 9 | 135 | 75 | 139 | 2.18 | B | 0.7 | 0.9 | |
12N9-4B-1 | 9 | 135 | 75 | 139 | 2.18 | B | 0.7 | 0.9 | |
12M9-4B-1 | 9 | 135 | 75 | 139 | 2.18 | B | 0.7 | 0.9 | |
12N9B-4B | 9 | 150 | 88 | 105 | 2.24 | A | 0.7 | 0.9 | |
12N10-3A | 10 |
135 | 90 | 145 | 2.52 | B | 0.99 | 1.0 | |
12N10-3A-1 | 10 |
135 | 90 | 145 | 2.52 | A | 0.99 | 1.0 | |
12N10-3A-2 | 10 | 135 | 90 | 145 | 2.52 | D | 0.99 | 1.0 | |
12N10-3B | 10 | 135 | 90 | 145 | 2.52 | B | 0.99 | 1.0 | |
12N10-3B-1 | 10 | 135 | 90 | 145 | 2.52 | A | 0.99 | 1.0 | |
12N11-3A | 11 | 135 | 90 | 155 | 2.96 | B | 0.99 | 1.1 | |
12N11-3A-1 | 11 | 135 | 90 | 155 | 2.96 | D | 0.99 | 1.1 | |
12N11-3B | 11 | 135 | 90 | 155 | 2.96 | B | 0.99 | 1.1 | |
12N12-3B | 12 | 202 | 76 | 134 | 2.397 | B | 0.99 | 1.2 | |
12N12A-4A | 12 | 134 | 80 | 160 | 3.1 | B | 0.99 | 1.2 | |
12N12A-4A-1 | 12 | 134 | 80 | 160 | 3.1 | B | 0.99 | 1.2 | |
12N14-3A | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
12N14-3A-1 | 14 | 134 | 89 | 166 | 3.565 | A | 0.99 | 1.4 | |
12N14-3B | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
12N14-4A | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
12M14-3A | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
12M16-3A | 14 | 134 | 89 | 166 | 3.565 | D | 0.99 | 1.4 | |
12N16-3A | 16 | 175 | 100 | 155 | 4.516 | B | 147 | 1.6 | |
12N16-3B | 16 | 175 | 100 | 155 | 4.516 | B | 147 | 1.6 | |
12N16-4B | 16 | 175 | 100 | 155 | 4.516 | B | 147 | 1.6 | |
12C16A-3B | 19 | 186 | 82 | 171 | 4.51 | G | 0.99 | 1.9 | |
12N18-3 | 18 | 205 | 90 | 162 | 5.19 | B | 147 | 1.8 | |
12N18-3A | 18 | 205 | 90 | 162 | 5.19 | C | 147 | 1.8 | |
12N18-3B | 18 | 205 | 90 | 162 | 5.19 | C | 147 | 1.8 | |
12N19AH | 19 | 186 | 82 | 171 | 4.51 | G | 0.99 | 1.9 | |
12N24-3A | 24 | 184 | 124 | 175 | 5.03 | G | 182 | 2.4 | |
12N24-3 | 24 | 184 | 124 | 175 | 5.03 | G | 182 | 2.4 | |
12N24-4 | 24 | 184 | 124 | 175 | 5.03 | G | 182 | 2.4 | |
YHD-12 | 28 | 206 | 133 | 165 | 7.118 | H | 2.1 | 2.8 | |
CHD4-12(H-12) | 28 | 206 | 133 | 165 | 7.118 | H | 2.1 | 2.8 |
